UltraFocus-XL
| ⇦ | ⇩ More Product information ⇩ | Home ⊳ |
Introducing UltraFocusXL by Faxitron—a larger, more versatile, fully shielded digital x-ray cabinet. Featuring an extra large field of view so you can image larger samples without sacrificing resolution. [TOP⇧] or [Return⇒]
FEATURES
- Larger cabinet and detector size lets you image samples currently too big for existing cabinet x-ray systems thanks to an expanded cabinet and larger 17" x 17" (43cm x 43cm) imaging area.
- Best-in-class resolution with native detector resolution of 100 microns and effective resolution up to 10 microns. Multiple levels of geometric magnification (up to 10X) allow imaging at the highest resolution.
- More versatile thanks to proprietary Automatic Exposure Control (AEC) which selects optimal x-ray exposure settings to ensure highest image quality for a broad range of biological and light NDT samples. Manual exposure mode also available for multi-layer samples and those containing a variety of components.
- Ergonomic design means this fully integrated, floor standing system with heavy duty casters fits easily into any lab and plugs into any standard A/C outlet.
- Easy to use with no extensive training or specialized x-ray knowledge required to operate. Intuitive software designed to meet the imaging needs of research and industrial users.
- Independently certified by a Nationally Recognized Testing Laboratory (Intertek) to the highest international standards.
- Remote diagnostics and support available from product specialists ready to help.
[TOP⇧] or [Return⇒]
| Specifications: | |
| Imaging Area | 43cm x 43cm (17” x 17”) |
| Pixel Pitch | 100µm (18.7 million pixels) |
| Scintillator | Direct deposited Csi |
| Magnification | Up to 10X |
| Spatial Resolution | 10µm at 10X magnification |
| Energy Range | 20 - 100kV |
| Tube Current | 1.0mA max (limited to 12W) |
| Focal Spot Size | <15µm |
| Tube Filtration | 0.25mm Be, tungsten source |
| Power Requirements | 100-240VAC, 50/60Hz |
| External Dimensions | 34” W x 31” D x 62” H (86cm x 79cm x 158cm) |
| Chamber Dimensions | 25” W x 25” D x 36” H (64cm x 64cm x 92cm) |
| Weight | 1,400lbs (635kg) |
