CellRad

CellRad

CellRad by Faxitron® is a dedicated cabinet x-ray cell irradiator designed for placement directly on the lab benchtop, arm’s-length from the incubator, eliminating the need to transport your cells to a core irradiation facility. The CellRad system allows you to irradiate cells without compromising sterility or security. It also serves as a smaller, simpler, safer and more cost-effective alternative to gamma radioisotope and high-powered x-ray irradiators.TOP】or【 Faxitron

FEATURES

  • Easy to use with an intuitive touch-screen control panel and no requirements for extensive training or additional x-ray shielding.
  • Secure system with password login
  • Integrated dosimeter with advanced Automatic Dose Control (ADC) for setting exact dose
  • Cost effective and free of costly licensing, security and source maintenance fees
  • Remote diagnostic and support from product specialists who put you and your research first
 TOP Faxitron Radiation

 TOP Faxitron Radiation



 Specifications:
 Energy range  10 - 130kV
 Tube current  0.1 - 5mA
 Tube power  650W
 Dose rate(130kVp, 5.0mA)

 up to: 50 Gy/min (unfiltered)
 up to: 13 Gy/min (0.5mm Al)

 Focal spot size  1.0 x 1.4mm
 Inherent filtration  1.6mm Be
 Beam angle  40° divergence
 Maximum coverage  12” (30cm)
 Source to object distance  17” (44cm)
 Exposure time  5 sec to 180 min (1 sec increments)
 Power requirements  100 - 230VAC +/- 10%, 50 - 60Hz
 Cooling  integrated closed-loop heat exchanger
 Specimen turntable  electrically operated, 2 RPM
 Dimensions external   30” H x 21” W x 24” D (77cm x 53cm x 61cm)
 Dimensions internal   14” H x 12” W x 12” D (37cm x 30cm x 32cm)
 Weight  460lbs (210kg)
 Shipping weight  540lbs (245kg)
